ANNAITE 315/70R22.5 Radial truck tyre
Suitable to driving wheels of trucks with good traction and high loading capability.
| Brand Name: | ANNAITE | ||||||||
| Pattern No. | 785 | ||||||||
| Technical Parameter: | |||||||||
| Tyre Size | Load & Speed symbol | Max.load(kg) | Relative | Inflated size | Standard Rim | Alternative Rim | |||
| pressure (kPa) | of new tire (mm) | ||||||||
| Single | Dual | Single | Dual | Sec.W | Out.D | ||||
| 11.00R22-18 | 154/151 L | 3750 | 3450 | 930 | 293 | 1135 | 8.0 | 22.0mm | |
| 11R22.5-16 | 146/143 M | 3000 | 2725 | 830 | 279 | 1054 | 8.25 | 18.0mm | |
| 12R22.5-18 | 152/148 M | 3550 | 3150 | 850 | 300 | 1084 | 9.00 | 18.0mm | |
| 13R22.5-18 | 154/151 K | 3750 | 3450 | 830 | 320 | 1124 | 9.75 | 18.0mm | |
| 275/70R22.5-18 | 148/145 M | 3150 | 2900 | 900 | 278 | 960 | 8.25 | 18.5mm | |
| 295/80R22.5-16 | 152/148 M | 3550 | 3150 | 850 | 298 | 1044 | 9.00 | 18.0mm | |
| 315/80R22.5-20 | 157/154 M | 4125 | 3750 | 900 | 310 | 1082 | 9.00 | 18.0mm | |
| 315/70R22.5-18 | 154/150 M | 3750 | 3450 | 900 | 311 | 1081 | 9.00 | 19.0mm | |
| 205/75R17.5-14PR | 124/122 M | 1600 | 1500 | 760 | 160 | 749 | 6.00 | 14.5mm | |
| 215/75R17.5-16PR | 135/133 J | 2180 | 2060 | 860 | 172 | 761 | 6.00 | 14.5mm | |
| 225/75R17.5-16PR | 129/127 M | 1850 | 1750 | 830 | 180 | 776 | 6.75 | 15.5mm | |
| 235/75R17.5-18PR | 143/141 J | 2725 | 2575 | 875 | 189 | 792 | 6.75 | 15.5mm | |
| 245/70R17.5-18PR | 143/141 J | 2725 | 2575 | 900 | 192 | 781 | 7.50 | 15.5mm | |
| 225/70R19.5-14PR | 128/126 M | 1800 | 1700 | 830 | 176 | 804 | 6.75 | 14.5mm | |
| 245/70R19.5-18PR | 143/141 J | 2725 | 2575 | 875 | 192 | 832 | 7.50 | 15.5mm | |
| 265/70R19.5-18PR | 143/141 J | 2725 | 2575 | 850 | 200 | 866 | 7.50 | 15.5mm | |
| 285/70R19.5-18PR | 150/148 J | 3350 | 3150 | 900 | 216 | 888 | 8.25 | 16.5mm | |
